Single Row NSK Taper Roller Bearing 32204 32205 32206 32207 32208 32209 32210 Bearing
Basic Info
Model No.: 32204 32205 32206 32207 32208 32209 32210
Product Description
Packaging Details: | 1.Industrial Packing: a)Plastic Tube+Carton+Pallet b)Plastic Bag+Kraft Paper+Carton+Pallet . 2.Commercial Packing a)Plastic Bag+Color Box+Carton+Pallet. 3. According to the Requirement of Customers. |
Delivery Detail: | within 7 days after confirmed this order |
Benefits: Used widely in transmissions, can be used in oil or greased, high radial and axial load Tapered Roller Bearings generally come in two parts - the cone (consisting of the inner ring and roller cage assembly) and the cup (outer ring). These two parts can be mounted separately. Tapered Roller Bearings are particularly suited to the accommodation of combined radial and axial loads
Products name | taper Roller Bearing |
Brand name | NSK |
model | 32204 32205 32206 32207 32208 32209 32210 |
material | Stainless steel.Gcr15.carbon steel |
Sealing | Open |
Quality standard | ISO9001:2000 standard |
Service | OEM service |
Delivery date | Within15-20 dayes |
Payment terms | A: 30% T/T in advance .70% against copy of B/L B: 30% T/T in advance .70% L/C C:Western union D:Paypal |
Application | Automobile, rolling mill, mine, metallurgy, plastic machinery and other industries |
Package | 1.polybag +box+carton 2.the users who have any requirement in packing may write them in the contract( customized ) |
Special properties
| 1. High precision 2. Low noise 3.long life 4. Can be customized according to your needs 5. Can provide small & miniature standard and non-standard ball bearings.
|
Taper roller bearings |
30202 series | 30202 30203 30204 30205 30206 30207 30208 30209 30210 30211 30212 30213 30214 30215 30216 30217 30218 30219 30220 30221 30222 30224 30226 30228 30230 30232 30236 30240 30244 |
30302 series | 30302 30303 30304 30305 30306 30307 30308 30309 30310 30311 30312 30313 3031430315 30316 30317 30318 30319 30320 30321 30322 30324 30326 30328 30330 30332 303525 | |
32204 series | 32204 32205 32206 32207 32208 32209 32210 32211 32212 32213 32214 32215 32216 32217 32218 32219 32220 32221 32222 32224 32226 32228 3223032232 32236 32238 32240 32244 32248 | |
32303 series | 32303 32304 32305 32306 32307 32308 32309 32310 32311 32312 32313 32314 32315 32316 32317 32318 32319 32320 32321 32322 32324 32326 32330 32334 | |
31303 series | 31303 31304 31305 31306 31307 31308 31309 31310 31311 31312 31313 31314 31315 31316 31317 31318 31319 31320 31324 31326 31328 31332 | |
32004 series | 32004 32005 32006 32007 32008 32009 32010 32011 32012 32013 32014 32015 32016 32017 32018 32019 32020 32021 32022 32024 32026 32028 32030 32032 32034 32036 32038 32040 32044 32048 32052 32056 32060 32064 |
Number | Unit | Cup OUTSIDE DIA. | Cone BORE | Cone WIDTH | Cup WIDTH | Bearing WIDTH | Max.Shaft Fillet Radii | Max.Hsng. Fillet Radii |
D | d | B | C | T | R | r | ||
30204 | mm | 47.000 | 20.000 | 14.000 | 12.000 | 15.250 | 2.5 | 1.6 |
in | 1.850 | 0.787 | 0.551 | 0.472 | 0.600 | 0.098 | 0.063 | |
30205 | mm | 52.000 | 25.000 | 15.000 | 13.000 | 16.250 | 2.5 | 1.9 |
in | 2.047 | 0.984 | 0.591 | 0.512 | 0.640 | 0.098 | 0.075 | |
30206 | mm | 62.000 | 30.000 | 16.000 | 14.000 | 17.250 | 2.5 | 1.9 |
in | 2.441 | 1.181 | 0.630 | 0.551 | 0.679 | 0.098 | 0.075 | |
30207 | mm | 72.000 | 35.000 | 17.000 | 15.000 | 18.250 | 3.0 | 2.3 |
in | 2.835 | 1.378 | 0.669 | 0.591 | 0.719 | 0.118 | 0.091 | |
30207/D80 | mm | 80.000 | 35.000 | 17.000 | 15.000 | 18.250 | 1.4 | 0.9 |
in | 3.150 | 1.378 | 0.669 | 0.591 | 0.719 | 0.055 | 0.035 | |
30208 | mm | 80.000 | 40.000 | 18.000 | 16.000 | 19.750 | 3.0 | 2.3 |
in | 3.150 | 1.575 | 0.709 | 0.630 | 0.778 | 0.118 | 0.091 | |
30209 | mm | 85.000 | 45.000 | 19.000 | 16.000 | 20.750 | 3.0 | 2.3 |
in | 3.346 | 1.772 | 0.748 | 0.630 | 0.817 | 0.118 | 0.091 | |
30210 | mm | 90.000 | 50.000 | 20.000 | 17.000 | 21.750 | 3.0 | 2.3 |
in | 3.543 | 1.969 | 0.787 | 0.669 | 0.856 | 0.118 | 0.091 | |
30211 | mm | 100.000 | 55.000 | 21.000 | 18.000 | 22.750 | 4.0 | 2.3 |
in | 3.937 | 2.165 | 0.827 | 0.709 | 0.896 | 0.157 | 0.091 | |
30212 | mm | 110.000 | 60.000 | 22.000 | 19.000 | 23.750 | 4.0 | 2.3 |
in | 4.331 | 2.362 | 0.866 | 0.748 | 0.935 | 0.157 | 0.091 | |
30213 | mm | 120.000 | 65.000 | 23.000 | 20.000 | 24.750 | 4.0 | 2.3 |
in | 4.724 | 2.559 | 0.906 | 0.787 | 0.974 | 0.157 | 0.091 | |
30214 | mm | 125.000 | 70.000 | 24.000 | 21.000 | 26.250 | 4.0 | 2.8 |
in | 4.921 | 2.756 | 0.945 | 0.827 | 1.033 | 0.157 | 0.110 | |
30215 | mm | 130.000 | 75.000 | 25.000 | 22.000 | 27.250 | 4.0 | 2.8 |
in | 5.118 | 2.953 | 0.984 | 0.866 | 1.073 | 0.157 | 0.110 | |
30216 | mm | 140.000 | 80.000 | 26.000 | 22.000 | 28.250 | 5.0 | 3.5 |
in | 5.512 | 3.150 | 1.024 | 0.866 | 1.112 | 0.197 | 0.138 | |
30217 | mm | 150.000 | 85.000 | 28.000 | 24.000 | 30.500 | 5.0 | 3.5 |
in | 5.906 | 3.346 | 1.102 | 0.945 | 1.201 | 0.197 | 0.138 | |
30218 | mm | 160.000 | 90.000 | 30.000 | 26.000 | 32.500 | 5.0 | 3.5 |
in | 6.299 | 3.543 | 1.181 | 1.024 | 1.280 | 0.197 | 0.138 | |
30219 | mm | 170.000 | 95.000 | 32.000 | 27.000 | 34.500 | 5.5 | 4 |
in | 6.693 | 3.740 | 1.260 | 1.063 | 1.358 | 0.217 | 0.157 | |
30220 | mm | 180.000 | 100.000 | 37.000 | 29.000 | 37.000 | 5.5 | 4 |
in | 7.087 | 3.937 | 1.457 | 1.142 | 1.457 | 0.217 | 0.157 | |
30221 | mm | 190.000 | 105.000 | 39.000 | 30.000 | 39.000 | 5.5 | 4.0 |
in | 7.480 | 4.134 | 1.535 | 1.181 | 1.535 | 0.217 | 0.157 | |
30222 | mm | 200.000 | 110.000 | 38.000 | 32.000 | 41.000 | 5.5 | 4 |
in | 7.874 | 4.331 | 1.496 | 1.260 | 1.614 | 0.217 | 0.157 | |
30224 | mm | 215.000 | 120.000 | 40.000 | 34.000 | 43.500 | 5.5 | 4 |
in | 8.465 | 4.724 | 1.575 | 1.339 | 1.713 | 0.217 | 0.157 | |
30303 | mm | 47.000 | 17.000 | 14.000 | 12.000 | 15.250 | 2.5 | 1.6 |
in | 1.850 | 0.669 | 0.551 | 0.472 | 0.600 | 0.098 | 0.063 | |
30304 | mm | 52.000 | 20.000 | 15.000 | 13.000 | 16.250 | 3.0 | 2.3 |
in | 2.047 | 0.787 | 0.591 | 0.512 | 0.640 | 0.118 | 0.091 | |
30305 | mm | 62.000 | 25.000 | 17.000 | 15.000 | 18.250 | 3.0 | 2.3 |
in | 2.441 | 0.984 | 0.669 | 0.591 | 0.719 | 0.118 | 0.091 | |
30306 | mm | 72.000 | 30.000 | 19.000 | 16.000 | 20.750 | 3.0 | 2.3 |
in | 2.835 | 1.181 | 0.748 | 0.630 | 0.817 | 0.118 | 0.091 | |
30306/H23 | mm | 72.000 | 30.000 | 19.000 | 18.000 | 23.000 | 3.0 | 2.3 |
in | 2.835 | 1.181 | 0.748 | 0.709 | 0.906 | 0.118 | 0.091 | |
30307 | mm | 80.000 | 35.000 | 21.000 | 18.000 | 22.750 | 4.0 | 2.3 |
in | 3.150 | 1.378 | 0.827 | 0.709 | 0.896 | 0.157 | 0.091 | |
30308 | mm | 90.000 | 40.000 | 23.000 | 20.000 | 25.250 | 4.0 | 2.3 |
in | 3.543 | 1.575 | 0.906 | 0.787 | 0.994 | 0.157 | 0.091 | |
30309 | mm | 100.000 | 45.000 | 25.000 | 22.000 | 27.250 | 4.0 | 2.8 |
in | 3.937 | 1.772 | 0.984 | 0.866 | 1.073 | 0.157 | 0.110 | |
30310 | mm | 110.000 | 50.000 | 27.000 | 23.000 | 29.250 | 5.0 | 3.5 |
in | 4.331 | 1.969 | 1.063 | 0.906 | 1.152 | 0.197 | 0.138 | |
30311 | mm | 120.000 | 55.000 | 29.000 | 25.000 | 31.500 | 5.0 | 2.8 |
in | 4.724 | 2.165 | 1.142 | 0.984 | 1.240 | 0.197 | 0.110 | |
30312 | mm | 130.000 | 60.000 | 31.000 | 26.000 | 33.500 | 5.5 | 4 |
in | 5.118 | 2.362 | 1.220 | 1.024 | 1.319 | 0.217 | 0.157 | |
30313 | mm | 140.000 | 65.000 | 33.000 | 28.000 | 36.000 | 5.5 | 4 |
in | 5.512 | 2.559 | 1.299 | 1.102 | 1.417 | 0.217 | 0.157 | |
30314 | mm | 150.000 | 70.000 | 35.000 | 30.000 | 38.000 | 5.5 | 4 |
in | 5.906 | 2.756 | 1.378 | 1.181 | 1.496 | 0.217 | 0.157 | |
30315 | mm | 160.000 | 75.000 | 37.000 | 31.000 | 40.000 | 5.5 | 4 |
in | 6.299 | 2.953 | 1.457 | 1.220 | 1.575 | 0.217 | 0.157 | |
30316 | mm | 170.000 | 80.000 | 39.000 | 33.000 | 42.500 | 5.5 | 4 |
in | 6.693 | 3.150 | 1.535 | 1.299 | 1.673 | 0.217 | 0.157 | |
30317 | mm | 180.000 | 85.000 | 41.000 | 34.000 | 44.500 | 7.0 | 4.5 |
in | 7.087 | 3.346 | 1.614 | 1.339 | 1.752 | 0.276 | 0.177 | |
30318 | mm | 190.000 | 90.000 | 43.000 | 36.000 | 46.500 | 7.0 | 4.5 |
in | 7.480 | 3.543 | 1.693 | 1.417 | 1.831 | 0.276 | 0.177 | |
30319 | mm | 200.000 | 95.000 | 45.000 | 38.000 | 49.500 | 7.0 | 4.5 |
in | 7.874 | 3.740 | 1.772 | 1.496 | 1.949 | 0.276 | 0.177 | |
30320 | mm | 215.000 | 100.000 | 47.000 | 39.000 | 51.500 | 7.0 | 4.5 |
in | 8.465 | 3.937 | 1.850 | 1.535 | 2.028 | 0.276 | 0.177 |
1) Taper roller bearings (Inch;Single Row;Double rows).
2) Deep groove ball bearings(Gcr15 Carbon Z 2Z RS 2RS) .
3) Pillow Block Bearings and seats(UCP UCF UCFL UCT).
4) Wheel Hub Bearing.
Wafang Dian Bearing Advantage
1) Material Advantage
All the material for Wafang Dian bearing are from the best suppliers in China.
2) Processing Advantage
we can guarantee the time spent and quality of every processing. We can do three times tempering to stabilize the dimensions of the bearings, which is quite different from Other Bearings manufacturers.
3) Quality control advantage
All the bearing parts are 100% strictly inspected before and during production including Metallurgical testing, crack detection, roundness, hardness, roughness and g++eometric dimensions.
4) All of bearings meet the ISO international standard.
5) Appearance Technology Advantage
we can provide light chamfer, black chamfer, black chamfer of the rollers. The bearings are produced all according to customer's requirements.
6) Service Advantage
Your satisfaction is our biggest goal. From quotation to the final packing and transport, we provide the quickest and most satisfactory services to every customer.
Company information
Our factory has been founded for around 30 years, We are a professional manufacturer of ball bearings and roller bearings, including deep groove ball bearing, self-aligning bearing, Cylindrical Roller Bearing, tapered roller bearings, with our good team work and hard working of skillful staffs and our professional engineers, we got very good reputation in the world market, especially in Mid-eastern countries. Thanks for every customer's support and trust, our company hope to establish mutual benefit and development business relations with you!
If you are interested in our products Deep Groove Ball Bearing, welcome to contact us for more detailed information, Your inquiry related to our product & price will be replied within 24hours Well-trained & experienced staff are to answer all your inquiries. OEM & ODM projects are highly welcomed. We have strong R&M team here to help. Free samples available The professional Logistic Center service Technical support after sale Any other reasonable requirements.
We participate Canton Fair,Shanghai Auto Mechanika Fair,Professional Auto Parts Fair annually.
Welcome Inquiry and order !
Thank you! Contact us if you need more details on Taper Roller Bearing. We are ready to answer your questions on packaging, logistics, certification or any other aspects about 32204 32205 32206 32207 32208 32209 3221 Bearing、32204 32205 32206 32209 Taper Roller Bearing. If these products fail to match your need, please contact us and we would like to provide relevant information.
